Move, zoom, rotate, and flip

Image transforms change the picture under the selection. Moving or resizing the stencil changes the selection itself. Both affect the resulting crop, but serve different controls.

Pan and zoom

Bind a CropperInstance and call moveImage(left, top) or zoomImage(factor). Zoom factors are relative: 2 zooms in, 0.5 zooms out. Core restrictions limit the result.

For a slider that describes an absolute zoom level, follow Absolute zoom. For mouse, touch and wheel configuration, see Gestures.

Rotate and flip

rotateImage(angle) adds a rotation in degrees. flipImage(horizontal, vertical) flips the selected axes. Quarter turns are the straightforward choice with the default restrictions; arbitrary-angle workflows may need an appropriate custom strategy, as in the mobile showcase.

Transforms are part of cropper state and are included in canvas export. Coordinates after rotation belong to the transformed image space. Sending only an unrotated rectangle to a server will not reproduce that result; include transforms or export the canvas.

Show code

Transitions and completion

Action options can disable animation with { transitions: false }. A continuously dragged control should use that option so it follows the pointer. Gesture primitives pair transformation calls with transformImageEnd(); custom stencil movement pairs with moveCoordinatesEnd() or resizeCoordinatesEnd().

To set the opening rotation and flips, use default transforms. Changing those defaults does not replace an explicit action on the current image.
